Electro-Voice Subwoofer 4 Ohms 800W 2x10" Cabinet - Black

SKU EVID-S10.1DB
Brand: Electro-Voice
Save $195.00 Save $195.00
Original price $974.00
Original price $974.00 - Original price $974.00
Original price $974.00
Current price $779.00
$779.00 - $779.00
Current price $779.00

Product Info

The Electro-Voice S10.1D Subwoofer 4 Ohms 800W 2x10" Cabinet is a compact, high-performance, dual 10" (254 mm) woofer loudspeaker with outstanding performance for the most demanding professional and commercial sound applications. Designed and engineered for use in background and foreground music, and sound reinforcement applications, the EVID-S10.1D is the ideal solution for indoor and outdoor applications, such as fitness clubs, leisure venues, and others.

Product details:

  • 2x10" subwoofer cabinet
  • Two 10 inch high-excursion woofers
  • Carefully engineered for outdoor environments (IP54 and IP65), without compromising performance
  • 400 W power handling provides for 120 dB maximum SPL (126 dB peak)
  • 70/100 V transformer input panel accessory available
  • Crossover input panel accessory available
  • Weight Net 39.46lbs (17.9kg)
  • Depth 19.33" (491mm) x Width 25.63" (651mm) x Height 14.02" (356mm)
  Ease of installation, and flexible options for mounting solutions and weather resistance, the EVID-S10.1D is the perfect solution for a wide variety of surface mount applications.

The EVID-S10.1D has been carefully engineered to resist outdoor environments, without compromising on performance for indoor applications. The subwoofer is IP54 rated, and its weather-proofing is complemented with exceptional cabinet and grille resistance against sun, salt and moisture. For the toughest weather conditions, the IP rating of the EVIDS10.1D can be upgraded to IP65, using the included port plug accessory.

The wide range of EVID surface mount speakers has been designed to work together as a complete system in a variety of different surface mount constructions, and to be used in combination with other EVID ceiling and in-wall speakers.



Frequency Range (-10 dB) 33 Hz – 500kHz
Shipping Weight 46.3lbs (21kg)
Weight Net 39.46lbs (17.9kg)

SPECIFICATIONS

Depth 19.33" (491mm)
Width 25.63" (651mm)
Height 14.02" (356mm)
Weatherized Yes
Connector Type Two removable locking 4-pin connector (Euroblock) – Input and output. Max. wire size 12 AWG (2.5 mm).
LF Transducer Two 10 inch (254 mm)
Max. SPL/1m (calc) 120dB
Sensitivity 1 W/1 m 94dB
Recommended High-Pass Frequency 40Hz
Available Color Black or White
Environmental Specs IP-54 (per IEC-60529); IP-65 with port covers
Nominal Impedance Stereo Mode: (2) 8ω; Mono Mode: (1) 4Ω
Power Handling (Continuous / Peak) 400W/1600W
Transformer Taps (Transformer Version Only) Optional Accessory
