Product Info

The Zoom Q2n-4K combines unrivaled audio with crisp 4K imaging to completely capture your virtual classes like never before. Compatible with USB mixers and any other device capable of connecting to the camera's 3.5mm mic input for any type of audio input signal. Powered by (2) AA batteries this device is able to work as either a web camera or as a video recorder to capture your fitness videos. With a simple connection into USB mixers, this provides you a complete easy to use camera solution to record or stream fitness videos or virtually any content!

The Camera for Lights & Action
The Q2n-4K’s high dynamic range (HDR) technology automatically adjusts the exposure based on your lighting.

Includes:

Product highlights:

USB interface for live streaming (at 720p resolution) and data transfer
12 ‘Scene’ options for use in different lighting environments, including ‘Auto’ setting that intelligently adapts to your environment
Built-in X/Y stereo microphones capable of handling sound levels up to 120 dB SPL
Can be used as a standalone audio recorder with data saved in WAV format up to 24-bit/96 kHz
5 field of view (FOV) settings
Records directly to microSD, microSDHC, and microSDXC cards up to 256 GB for extended recording times (SD card included in this bundle)
Easy one-button recording
Color LCD
Support for three HD video modes: 720p, 1080p and 4K
Video bitrates up to 76 Mbps for improved image quality
Frame rates: 4K/30fps, 4K/25fps, 4K/24fps, 1080p/60fps, 1080p/50fps, 1080p/30fps, 1080p/25fps, 1080p/24fps, 720p/30fps, 720p/25fps
HDMI video output for connection to HDTVs, selectable between NTSC and PAL
Records video (with audio) in MOV format
Analog-style level control with on-screen digital metering
Auto Gain function gives automatic control over audio input level
Stereo input for use with external devices plus support for plug-in power
Headphone/line-level output for fast audio monitoring
Low-cut filter for the elimination of low-frequency noise and rumble
High-quality 150° wide-angle lens (f2.8/15.2 mm)
Compatible with OBS Open Broadcaster Software, Skype and other popular streaming applications
USB mic function (with low-latency direct monitoring) when used with computers and iOS devices (Apple Camera Connection Kit or Lightning to USB Camera Adapter required for use with iOS devices)
Operates with two AA batteries
Built-in standard tripod mount
*iPad Camera Connection Kit or Lightning to USB Camera Adapter required (sold separately).

More Info

Live Stream with Great Audio
The Q2n-4K is also a webcam, able to stream virtual classes live to Facebook, YouTube, Twitch, and more. With a micro HDMI video output, the Q2n-4K also lets you watch your video in high definition on your TV.

• POINT • Easily frame your shot using five fields of view (FOV) settings, allowing zooming and wide shots without moving the camera.
• AIM • The Q2n-4K’s 150-degree lens and color LCD make it easy to frame the perfect shot.
• CAPTURE • At the touch of a button, the Q2n-4K captures premium video recording at up to 4K Ultra HD resolution onto a Micro SD card (sold separately).

Specs

Image Sensor:

1/2.3" 16 M-flexible CMOS sensor

Lens:

F 2.8, 150° FOV

Video Format:

MPEG-4 AVC/H.264 (MOV)

Video resolutions:

4K: 30 p, 25 p, 24 p
1080: 60 p, 50 p, 30 p, 25 p, 24 p
720: 30 p, 25 p

Audio Formats:

WAV: 96 kHz/24-bit, 48 kHz/24-bit, 44.1 kHz/16-bit

Audio Functions:

• LO-CUT: Off, 80 Hz, 120 Hz, 160 Hz
• AUTO GAIN: OFF, CONCERT, SOLO, MEETING
• DELAY: 0.0 F, 0.5 F–10.0 F (only during web camera use)
• DIRECT MONITOR ON/OFF (only during USB mic use)

Image functions:

FOV (5 steps): WIDE–0–TELE

SCENE Settings
• AUTO
• OUTDOOR
• SUNSET
• NIGHT
• CONCERT LIGHT
• JAZZ CLUB,
• DANCE CLUB
• MONOCHROME
• SEPIA
• FILM
• X-PROCESS
• FLAT

Display:

1.77" four-color LCD (160 × 128)

Audio inputs:

Mic
Fixed 120° XY stereo mic
Maximum sound pressure: 120 dB SPL
Input gain: −∞ dB – +39 dB

Line
Input connector: stereo mini jack (supports plug-in power)
Input gain: −∞ dB – +39 dB
2 kΩ or higher input impedance
Plug-in power (2.5 V) supported

Output connector:

Combined headphone/line stereo mini-jack
HDMI micro Type D

Built-in speaker:

300 mW 8 Ω mono speaker

Recording media:

microSDHC/microSDXC (class 10 or higher, 256 GB maximum)

USB:

Connector: USB2.0 Micro-B

WEBCAM
Class: UVC 1.0 + UAC 1.0
Formats: 720 p WVGA video, 48 kHz/16-bit audio

CARD READER
Class: USB Mass Storage

USB MIC
Class: UAC 1.0
Format: 44.1 kHz/16-bit
Note: Card reader and USB mic functions support iOS/iPadOS devices

Supported cable: USB2.0 Micro-B cable
Use cables for data transfer. Cables for battery-charging cannot be used for the above purpose.

Power:

2 AA batteries : alkaline LR6 (1.5 V), nickel metal hydride HR6 (1.2 V) or lithium FR6 (1.5 V)
AC adapter (ZOOM AD-17): DC 5 V/1 A
Note: USB bus power supported

Estimated continuous recording time using batteries:

Video resolution	Alkaline LR6 (1.5 V)	Ni-MH HR6 (1.2 V)	Lithium FR6 (1.5 V)
720/30 p	2.0 hours	3.0 hours	6.0 hours
1080/30 p	1.2 hours	2.0 hours	4.0 hours
4K/30 p	0.5 hours	1.0 hours	2.0 hours

Audio quality: 48 kHz/24-bit

• The above values are approximate.
• Continuous battery operation times were determined using in-house testing
methods. They will vary greatly according to use conditions.

External dimensions:

Main unit (maximum dimensions): 58.7 mm (D) × 68.5 mm (W) × 83.0 mm (H)

Weight (main unit only):

124 g
