Product Info

Electro-Voice's ZLX-15 speaker gives you the confidence of the industry's most trusted components engineered to exacting standards to bring exceptional EV audio quality for larger applications, with or without a subwoofer.

15" woofer for extended low-frequency response and 1.5 high-frequency titanium compression driver
44 Hz and 20 kHz frequency range
250 W continuous and 1000 W peak power handling
96 dB SPL sensitivity; 126 dB max SPL
36.5 lbs (16.6 kg)

Specs

Specifications

Axial Sensitivity (SPL, 1 W @ 1 m)	96dB
Frequency Range	44 Hz - 20 kHz
MaximumSPL	126dB
Nominal Impedance	8 Î©
Power Handling (Continuous / Peak)	250 / 1000 W
Frequency Response	56 Hz - 18 kHz
Recommended High-Pass Frequency	40Hz
MaximumSPL(1%THD)	0dB
Coverage (Nominal -6dB) H	90 Â°
Coverage (Nominal -6dB) V	60 Â°
LFTransducer	EVS-15L, 380 mm (15 in) Woofer
HFTransducer	DH-1K
Crossover Frequency	1700Hz
Minimum Impedance	7 Î©
Connector Type	Dual NL4
Enclosure Material	Polypropylene
Grill	18 Gauge Steel with Black Powder Coat
Height	685mm(26.97")
Width	423mm(16.65")
Depth	383mm(15.08")
Weight Net	16.6kg(36.6lbs)
Shipping Weight	22kg(48.5lbs)
